This wireless module is built around the Nordic nRF24L01+ transceiver and comes with an integrated Power Amplifier (PA) and Low Noise Amplifier (LNA), delivering a reliable communication range of up to 1,000 meters. Operating in the 2.4GHz ISM band, it offers enhanced performance over the classic nRF2401A by introducing additional data pipelines, improved buffering, and an auto-retransmission feature.

Its incredibly easy to integrateno complex RF design needed. Simply reserve an 8-pin interface and use the standard SPI protocol to manage data transmission with minimal effort.

Features

License-free 2.4GHz ISM band Use it globally without restrictions

Integrated Power Amplifier & LNA Enhanced signal strength & low noise

Max Output Power: ~20dBm

Receiver Sensitivity: ~-95dBm

External SMA Antenna For easy upgrades and better performance

Data Rate Options: 250kbps / 1Mbps / 2Mbps

Range: Over 1000+ meters (line of sight)

Voltage Supply: 1.9V to 3.6V

Precision Crystal: 60ppm @ 16MHz

5V Tolerant Inputs Flexible integration with different systems
